Hardware and Software Specs

Scanner Image
Scanner Make/Model CR5400 Scanner M500 Scanner 7203.110 Scanner Wisescan 600 Scanner AT10K RFID Scanner
Scans Global & US IDs
Scans Passports
Reads mDLs
Double Sided ID Card Reader
Automated
3-Light Sources (Ultraviolet, infrared and white light)
Processing High Processing Speed USB 2.0 High Speed USB 3.0 High Speed USB 2.0 High Speed High Processing Speed
Power Source USB AC Power AC Power AC Power AC Power
Connectivity 2.0 USB 2.0 USB 3.0 USB 2.0 USB 2.0 USB/ethernet
Dimensions 6.97” L x 4.25” W x 4.53” H 4.8” H x 5.7” W x 8.5” D 166 x 123 x 125 (mm) 126 W x 163 D x 87 H (mm) 7.4” L x 6.3” W x 2.6” H
Image Resolution up to 630 DPI 600 DPI 600 DPI 300/600 DPI 370/550 DPI
Factory Warranty 2 years 1 year 1 year 1 year 2 years
Extended Veridocs Warranty 2 years 1 year 1 year 1 year 2 years

Hardware Available through Veridocs

CR5400 Reader

The CR5400 document reader utilizes color-coded LED lights to provide a real-time status response that is optimal for 1D-1 sized documents such as driver’s licenses, identification cards and international identification cards. There’s no incorrect way to insert the card into the reader, making it extremely user-friendly.

    • Captures images of both sides of ID-1 documents simultaneously
    • Full-color images in white light
    • Captures images in Ultraviolet-A (UV-A) and Near-Infrared (NIR) light
    • Reads 1D and 2D barcodes
    • Automated ejection of the ID Cards after processing
    • Weight: 2.2 lbs.
    • Dimensions 6.97” L x 4.25” W x 4.53”H
    • Resolution up to 630 DPI
    • Connectivity 2.0 USB
    • Power USB/AC
    • High Processing Speed

    All CR5400 readers are covered under a two (2) year factory warranty from date of delivery. Veridocs offers additional warranty coverage past the two (2) years, which is available at the time of purchase.

AT10K RFID

The AT10K RFID scanner is designed to inspect, authenticate or capture data from travel and identity documents quickly and reliably in a wide variety of government and commercial applications with a 550 DPI camera.

    • Captures images of ID-1, ID-2 and ID-3 documents
    • Four Color Status LEDs
    • Captures images in white light, Near Infrared B900 light, and Ultraviolet light (UV-A)
    • OCR data capture of the Machine Readable Zone (MRZ)
    • Reads 1D and 2D barcodes from paper and mobile devices
    • Reads contactless chips
    • Reads Mobile Digital Licenses (mDL)
    • Anti-glare technology
    • Auto-triggering of document capture – presence of document is automatically detected
    • Removable hood
    • Weight: 2.4 lbs.
    • Dimensions 7.4” L x 6.3” W x 2.6”H [without hood] 4.0”H [with hood]
    • Resolution 370 DPI standard/550 DPI additional option
    • Connectivity 2.0 USB/Ethernet
    • Power USB/Ethernet/AC Power
    • High Processing Speed

    All AT10K RFID readers are covered under a two (2) year factory warranty from date of delivery. Veridocs offers additional warranty coverage past the two (2) years, which is available at the time of purchase.

M500 Reader

The M500 forensic reader extracts hidden security features on a drivers’ license or any identity card for authentication purposes in addition to reading and decoding the electronic information contained in the barcode or magnetic stripe. Both sides of the submitted card are also captured with the high-resolution imager during this single card insertion. The captured data can be analyzed on the host computer via the TWAIN connection.

The M500 also incorporates a high performance PDF417 decoder, 3 Track magnetic reader, along with a high-speed USB device as standard capabilities.

    • Duplex Multi-Color Scanner
    • Full-color images in white light
    • Captures images in Ultraviolet-A (UV-A) and Near-Infrared (NIR) light
    • High Performance 2D/Linear Barcode Reader
    • Integrated 3 Track Magnetic Strip Reader (ANSI, ISO, CDL, AAMVA)
    • Automated ejection of the ID Cards after processing
    • Single Pass Operation
    • Jam Free
    • Weight 4.25 lbs.
    • Dimensions 4.8”H x 5.7” W x 8.5” D
    • Resolution 600 DPI
    • Connectivity 2.0 USB
    • Power USB/AC
    • USB 2.0 High Speed

    All M500 readers are covered under a one (1) year factory warranty from date of delivery. Veridocs offers additional warranty coverage past the one (1) year, which is available at the time of purchase.

Regula 7203.110 Reader

The 7203.110 document reader allows single pass duplex scanning and capturing images of documents in white, infrared, ultraviolet, transmitted white and transmitted infrared lights. It is intended for automatic reading and authenticity verification of questioned documents.
The document reader provides the capability of capturing images, text data recognition, reading of 1D and 2D barcodes and optionally can capture magnetic stripe data.

    • Captures images of both sides of ID-1 documents simultaneously
    • Captures images in Ultraviolet-A (UV-A) and Near-Infrared (NIR) light
    • Anti-glare technology
    • Automatic selection of UV illumination intensity according to the document type
    • Reads 1D and 2D barcodes
    • OCR of the visual zone
    • Analyzes and compares text data
    • Automatic scanning after document detection
    • Automated ejection of the ID Cards after processing
    • Weight 1.7 lbs.
    • Dimensions mm 166L x 123W x 125H
    • Resolution: 600 DPI
    • Connectivity 3.0 USB
    • Power USB/AC Power
    • USB 3.0 High Speed

    All 7203.110 readers are covered under a one (1) year factory warranty from date of delivery. Veridocs offers additional warranty coverage past the one (1) year, which is available at the time of purchase.

WiseScan600 Scanner

The WiseScan600 scanner uses three light sources to identify hidden security features on a drivers’ license or any similarly sized identity card for authentication purposes. In addition, the scanner reads and decodes all the electronic information contained in the barcode or magnetic stripe. Both sides of the submitted card are captured with this single card insertion. The captured data is quickly passed over to the workstation to be analyzed and authenticated.

    • Captures images in white light, Near Infrared B900 light, and Ultraviolet light (UV-A)
    • 3-Tracks Magnetic Stripe Reader
    • Patented Card Transfer Mechanism for Jitter-Free Image
    • Forced Alignment Mechanism to Prevent Image Skew
    • Captures images of both sides of the document simultaneously
    • Plug-and-Play Connection via High-Speed USB 2.0 Interface
    • High-Performance 2D and Linear Barcode Reader.
    • No Required Cleaning Card
    • Weight 1.6 lbs.
    • Dimensions (mm) 126 W x 163 D x 87 H
    • Resolution 300/600 DPI
    • Connectivity 2.0 USB
    • Power USB/AC Power

    All WiseScan600 readers are covered under a one (1) year factory warranty from date of delivery. Veridocs offers additional warranty coverage past the one (1) year, which is available at the time of purchase.

Software Specifications

Single Server Development (combined)

    Windows 2012 or better with all service packs
    Memory - 4 GB Minimum + 1 GB for every 20 users over the first 20
    ASP.Net Core / .Net Core 2.2.2 (Runtime and Hosting)
    .Net 4.7.2 Framework
    SQL Server 2012 2014 2016 2017 (Standard or Enterprise recommended)
    Full Text Indexing
    Mixed Mode Authentication
    Minimum 100 GB free space on hard drive. Additional space needs are determined by volume and data retention policies.
    IIS Server Installed
    TCP/IP Port 443 unblocked for intranet clients
    Outbound port 443

Multiple Server Deployment

    Windows 2012 or better with all service packs
    Memory - 4 GB Minimum + 1 GB for every 20 users over the first 20
    .Net 4.7.2 Framework
    SQL Server 2012, 2014, 2016, 2017 (Standard or Enterprise recommended)
    Full Text Indexing
    Mixed Mode Authentication
    Minimum 100 GB free space on hard drive. Additional space needs are determined by volume and data retention policies
    Windows 2012 or better with all service packs
    Memory - 2 GB + 1 GB for every 50 users
    .Net 4.7.2 Framework
    IIS Server Installed
    Minimum 20 GB free space on hard drive
    TCP/IP Port 443 unblocked for intranet clients
    Outbound port 443
    Windows 8.1 Professional or better (32-Bit OS or 64-Bit OS) with latest service packs
    .Net 4.7.2 Framework
    Ability to connect to intranet server on port 443 - Inbound/Outbound
    Memory 2 GB or better
    At least 1 GB of free disk space
    Virtual memory ensure paging file size is set greater than zero to an appropriate level
    Minimum resolution 1024 x 768
    USB 2.0
    CPU capable of processing 30 gigaflops (Floating Point Operations per Second) will achieve authentication results in or around 11 seconds
    Disable USB Sleep settings: Control Panel - Power Options menu - Change plan settings - Change advanced power settings - USB settings - Disabled
